Implement thermal energy storage to decarbonize industry

解释人
WBCSDWBCSD

总结

Thermal energy storage can lower energy costs, decarbonize processes, and improve operational resilience of industrial companies.

Context

Industry accounts for 25% of total CO₂ emissions from energy systems, with process heat making up nearly two-thirds of industrial energy demand. Today, more than 80% of this heat still comes from fossil fuels, making its decarbonization essential for achieving net-zero emissions. Fortunately, various renewable heating solutions, such as heat pumps, solar thermal, and thermal energy storage, are already commercially available

Unfortunately, there are currently only a handful of industrial TES projects operational worldwide. Nevertheless, TES has broad industrial applicability due to its ability to supply high-temperature heat (already up to 600°C) while maintaining a small footprint. It is estimated that this technology alone could replace up to 40% of global gas use in industry today and avoid up to 14% of global projected energy-related greenhouse gas emissions by 2050.[1]


Solution

Thermal energy storage (TES) solutions work by heating a storage medium – such as water, molten salts or solid materials – using energy from renewable or non-renewable sources and storing the resulting thermal energy for later use. They are particularly effective when used in combination with renewable energy as they can capture it when it is less expensive and abundant and release it when it is scarce and expensive. TES solutions can be charged directly by heat, generated for example by a concentrated solar thermal plant (heat-to-heat), or by electricity using resistive heating (power-to-heat).

Figure 1: Simplified schema of thermal energy storage use in industry

Depending on how they store heat, TES solutions have three categories – sensible, latent, and thermochemical.

  • Sensible TES solutions increase the temperature of a solid or liquid material insulated from the surroundings. For example, thermal concrete is heated to the desired temperature, stores the heat, and releases it when needed by an industrial process.

  • Latent TES solutions make use of the phase change of materials (when a material changes from one state of matter to a different one, such as the vaporization of liquids or the melting of metals) to store energy.

  • Thermochemical TES solutions rely on chemical reactions that absorb heat during charging and release the stored heat when reversed.


Usage

Project details

Decisive parameters

Barriers faced

Success factors

Ease of process integration

Avery Dennison – Energynest – Solarlite-Azteq

Turnhout, Belgium

Chemicals

5 MWh + 2.7 MW concentrated solar thermal

Commissioned in 2023

Efficient use of the energy generated by the solar thermal field.

High efficiency of the solution.

No need for energy conversion (heat-to-heat solution).

Designing a solution that would allow the TES to operate autonomously within the solar thermal control system was a challenge. In the end, direct integration using valve-skid was chosen to increase efficiency and ensure constant output temperature.

Strong decarbonization targets set by Avery Dennison.

The long lifetime of TES as well as of the solar thermal solution.

Co-financing by the local community coupled with a grant reduced the financial risks to the main stakeholders.

Having a consortium of several suppliers enabled the sharing of risks and competencies.

Easy integration with standard heat exchangers as the system uses thermal oil, which is used by Avery Dennison as well.

Yara International –Energynest

Porsgrunn, Norway

Chemicals

4 MWh

Commissioned in 2023

The TES is capable of very short charge and discharge duration (5-6 cycles per hour) and is tailored to balance steam demand at Yara’s fertilizer production site.

The TES can be directly integrated into the existing utility network and uses the same heat transfer media.

The implementation of a first-of-a-kind fully autonomous system involved increased engineering effort to ensure compliance with site requirements.

Joint commitment from Yara and Energynest to reduce indirect CO2 emissions by improving the efficiency of the steam grid. The extra steam is used for additional on-site electricity generation.

Availability of grants from ENOVA and Innovation Norway supporting the project.

The TES has been integrated into the steam grid of the plant during a regular maintenance stop.

The TES uses the same piping specifications as the steam grid, which eases inspection and maintenance.

The TES is also fully integrated in the plant control system, centralizing control as well as data logging.

PepsiCo – Eneco – Kraftblock

Broek op Langedijk, The Netherlands

Food & Beverage

70 MWh (with extension to 150 MWh)

Planned commissioning in 2025

Favorable techno-economics

The TES solution received a connection to the grid more easily as it provides flexible capacity (using the connection only when demand is low).

Scalability across sites and applications.

The TES module was adjusted to the requirements of PepsiCo and thus it can be more easily replicated across PepsiCo sites.

Longer permitting (in particular due to visual impact)as the additional electrical equipment needed to be located outside of the current industrial building zone

Some difficulty fitting the solution into an existing industrial site as it required approximately 400m2 to fit the TES as well as all the integration and electrical equipment.

Eneco owns and operates the asset and provides hot air to PepsiCo to heat thermal oil under a Heat-as-a-Service agreement.

The system is designed so that Eneco can provide ancillary services to the grid.

Eneco and PepsiCo developed their internal capabilities as they compared several low-carbon solutions before the project.

The commissioning of charging, storage and discharging can be done separately in downtime.

Most components are off-the-shelf (heating, heat exchangers etc.), derisking the project, but they still require individual design and integration due to adaptation to customer’s site.


Impact

Sustainability impact

Climate

TES can cover 100% of the industrial heat demand, thus completely eliminating emissions from industrial process heat if renewable energy is used for charging. Additionally, even if electricity from the grid is utilized, the charging times typically align with periods of high renewable electricity generation. This means that the carbon intensity of the electricity used is usually much lower than average grid carbon intensity.

The lifecycle emissions of TES vary depending on the solution and technology used. However, they are generally significantly lower per MWh than in case of Li-ion batteries.

Therefore, typical emissions reduction is 200-400 kg CO2-eq per MWh of heat supplied by the TES.

Nature

TES have limited land footprint and can be installed into existing industrial sites, not needing additional land.

Social

TES eliminates local air pollution (NOx and other harmful emissions) associated with conventional combustion of fossil fuels.

Business impact

Benefits
  • The advantages of TES solutions compared to conventional heat generation and even other renewable heating solutions, such as heat pumps or solar thermal, are:

  • They provide on-demand or continuous heat, while complementing renewable heat and electricity generation by making use of it when it is abundant and inexpensive.

  • They can offer flexibility services to the electricity grid, providing an additional revenue stream.

  • They have a limited land footprint (2-4m2/MWh) fitting into existing industrial sites.

  • They can supply heat at a wide range of temperatures (already up to 600°C) and can be connected to existing steam networks.

  • They can be combined with a steam turbine to generate both heat and electricity, depending on the industrial process requirements and the local electricity market design.

Key commercial parameters

Value

Context

Capital expenditure

80-235 €/kWh* (full price)[1]

20-100 €/kWh (only TES stack)

↑ Ancillary equipment such as transformers, substations, and steam turbines

↑ Civil works required due to the weight or size of the TES system

↑ Process temperature requirements closer to the storage temperature

↑ Design modifications to enable, for example, faster charging and discharging

↑ Additional piping and other integration equipment

↓ Larger plants benefit from economies of scale, because engineering, procurement, and construction costs, along with the price of any ancillary equipment remain relatively fixed. For smaller projects, these additional costs can reach up to 150 €/kWh.

Operational cost

0.5-1.8% of CapEx annually (excludes price of charging)

The operational costs here exclude the price of charging (i.e. the cost of electricity or heat), as they vary significantly based on geographical location and TES use case.

Primary operation and maintenance costs stem from replacing electric resistive heaters, typically required every 7-10 years.

Levelized Cost of Heat

40-200 €/MWh (including charging)[ii]

The levelized cost of heat (LCOH) of TES is primarily determined (50%-80%) by the price of electricity or heat used for charging. The technical appendix of Systemiq’s report on electrothermal energy storage provides generic LCOH calculations for several European and US markets.

The levelized cost of storage (i.e. excluding the price of electricity or heat) is as low as 5-30 €/MWh.(6)

The use of behind-the-meter solar or wind generation can further reduce the LCOH by avoiding or at least lowering grid fees.

* Unlike other renewable heating solutions, where CapEx is based on the system's output capacity (measured in kW), the CapEx of TES depends primarily on the amount of energy it can store (measured in kWh).


Implementation

Typical business profile

Thermal energy storage solutions are currently best suited for companies in sectors such as food and beverage, pharmaceuticals, paper & pulp, or chemicals, which use low and medium temperature heat. As the technology matures, they may be viable even for high temperature industries including steel and cement.

Approach

TES can be delivered as a standard capital investment by a dedicated solution provider. However, it especially excels in combination with heat-as-a-service where the industrial company partners with a utility company. The typical structure would then look as follows:

  • Utility: Finances, owns and operates the TES. It also secures the cheap electricity thanks to its expertise in electricity trading. It sells the heat generated to the industrial company per MWh and collects additional revenue by using the TES for ancillary services supporting the grid.

  • Industrial company: Buys the heat as it is generated. It avoids the need for large capital investment as the TES is owned by the utility.

  • Solution provider: Supplies and builds the TES as an EPC contractor.

Stakeholders involved

  • Manufacturing plant director: The TES supplies hot water or steam which are instrumental to the manufacturing processes. The implementation project therefore requires strong buy-in from the plant leadership.

  • Operations: In addition to the plant leadership, company-level operations professionals should bring in specialized expertise and experience from similar projects.

  • Finance: TES represents a large capital investment which in most companies requires approval of an investment committee including finance professionals.

  • Sustainability: Implementation of TES significantly reduces Scope 1 emissions and should be included in long-term emissions reduction plans.

Key parameters to consider

  • Grid connection: TES solutions typically require grid connection upgrades and dedicated electrical infrastructure as they concentrate charging into short periods of very high peak load – several times higher than comparable electric boilers. However, securing this additional capacity is generally easier, since TES systems can be deployed flexibly when grid capacity is available and there is an oversupply of renewable electricity.

  • Electricity price volatility: The electricity price volatility is key for commercial viability, as it allows the TES system to charge at low prices and provide ancillary services to the grid. In favorable markets, payments for these services can account for up to 40% of the revenue generated by the TES solution.

  • Frequency of charging cycles: Higher frequency of cycles (i.e., times the storage is charged and subsequently discharged) improves the economic viability of TES solutions by distributing CapEx over more uses. As a result, most current TES systems are designed for at least 1 cycle per day.

  • No reduction in capacity: TES solutions do not experience a noticeable reduction in capacity throughout their lifetime if properly maintained. They are typically designed for 15,000 and, in some cases, even 300,000 cycles (compared to 6,000-8,000 cycle lifetime of standard Li-ion batteries).

Implementation and operations tips

Common implementation success factors reported by companies are:

  • Availability of capital subsidies and/or Heat-as-a-Service financing models

  • Availability of on-site energy generation or possibility to connect to the grid as a flexible asset

  • TES system design modifications to fit industrial company requirements
